Concrete Mixer Specifications:
| Model | CM80H | CM120H | CM130H | CM140H | CM160H | CM180H | CM200H | CM220H | CM240H | CM260H |
|---|---|---|---|---|---|---|---|---|---|---|
| DrumCapacity | 80L | 120L | 130L | 140L | 160L | 180L | 220L | 220L | 240L | 260L |
| Motor power | 250W | 550W | 550W | 550W | 650W | 800W | 800W | 750W | 750W | 750W |
| Drum Rotation Speed | 28-32 | 28-32 | 24-29 | 24-29 | 24-29 | 24-29 | 24-29 | 20-25 | 20-25 | 20-25 |
| Upper Drum Thickness | 1.2mm | 1.2mm | 1.5mm | 1.5mm | 1.5mm | 1.5mm | 1.5mm | 1.5mm | 15mm | 1.5mm |
| Bottom Drum Thickness | 1.5mm | 1.5mm | 2mm | 2mm | 2mm | 2mm | 2mm | 2mm | 2mm | 2mm |
| Mixing Drum Size | 330mm | 330mm | 380mm | 380mm | 380mm | 380mm | 380mm | 380mm | 380mm | 380mm |
| Overall Size(L×W×H) | 730*580*370mm | 730*580*430mm | 835*690*390mm | 835*690*430mm | 835*690*470mm | 835*690*480mm | 835*690*500mm | 970*760*460mm | 970*760*480mm | 970*760*500mm |
| W./N.W. | 38kg/41kg | 43kg/48kg | 51kg/56kg | 53kg/58kg | 57kg/61kg | 59kg/66kg | 60kg/67kg | 76kg/90kg | 82kg/91kg | 87kg/92kg |
