Main Technical Parameters:
| Parameter Description | Value |
|---|---|
| Model of generator set | DG11000E |
| Frequency (Hz) at 50/60 | 50 |
| Maximum output (kw) | 10 |
| Rated output (kw) | 9.5 |
| Rated voltage (V) | 220 |
| Power factor (cosФ) | COSФ=1 |
| DC output (V) | 12V/8.3A |
| Phase | Single phase |
| Motor form | Self-excited |
| Starting system | Electric start |
| Noise level at 7m | 80 - 85 |
| Fuel tank capacity | 27 |
| Continuous working hours | 10.5 |
| Engine model | HR1102FA |
| Engine type | Single-cylinder, vertical, 4-stroke, air-cooled diesel engine |
| Bore×Stroke (mm) | 102×88 |
| Fuel | 0# or -10# clean diesel |
| Lubricating oil volume (l) | 1.65 |
| Combustion system | Direct injection |
| Voltmeter | Yes |
| AC output socket | 2 |
| AC circuit breaker | Yes |
| Oil warning light | Yes |
| Oil alarm | Yes |
| DC circuit breaker | Optional |
| Timer | Optional |
| Big wheel | Optional |
| Three-phase voltage | Optional |
| Ammeter | Optional |
| Automatic transfer switch | Optional |
| Remote control function | Optional |
| Welding function | None |
| Dimension (mm) | 950×630×720 |
| Net weight (kg) | 155 |
Our company also offers other models, welcome to negotiate by email.
