Main Technical Parameters:
| Item | GF - 190KVA | GF - 250KVA | GF - 300KVA | GF - 375KVA | GF - 450KVA | GF - 500KVA | GF - 560KVA |
|---|---|---|---|---|---|---|---|
| Prime Power (KW/KVA) | 150/188 | 200/250 | 250/313 | 300/375 | 360/450 | 400/500 | 450/562 |
| Standby Power (KW/KVA) | 164/205 | 212/265 | 264/330 | 312/390 | 372/465 | 412/515 | 462/578 |
| Engine Model | SC7H250D2 | SC9D340D2 | SC13G420D2 | SC15G500D2 | SC25G610D2 | SC25G690D2 | SC27G755D2 |
| Number of cylinders | / | 6 in line | 6 cylinders in line | / | 12 in "V" V-shaped 12 cylinders | / | / |
| Bore and Stroke (mm) | 105x124 | 114x144 | 135×150 | 135x165 | 135x150 | 135x150 | 135x155 |
| Displacement (L) | 6.5 | 8.82 | 12.88 | 14.16 | 25.8 | 25.8 | 26.6 |
| Rated RPM (r/min) | / | / | / | 1500 | / | / | / |
| Rated Fuel Consumption (Sg/KW-h) | 193 | 195 | 200 | 200 | 202 | 202 | 202 |
| Diesel Generator Type | Inline, water-cooled, four-stroke | / | / | / | V-shaped 12 cylinders, water-cooled, four-stroke | / | / |
| Voltage (V) | 220/380, 230/400, 240/415 | / | / | / | / | / | / |
| Frequency (Hz) | 50 | / | / | / | / | / | / |
| Rated Current (A) | 296 | 383 | 476 | 563 | 718 | 821 | 884 |
| Phase | 3 | / | / | / | / | / | / |
| Power Factor | / | / | / | 0.8 | / | / | / |
| Connecting Type | Three-phase four-wires, "Y" type connecting | / | / | / | / | / | / |
| Exciter Type | Brushless, self-exciting | / | / | / | / | / | / |
| Open Type's Dimension LxWxH (mm) | 2400x850×1600 | 2400x850×1600 | 2650x1000×1750 | 2900×1000×1750 | 3200×1300×1800 | 3200×1300×1800 | 3500x1450×1950 |
| Net weight of open type (kg) | 1700 | 1850 | 2100 | 2500 | 3400 | 3800 | 4000 |
| Silent Type's Dimension LxWxH (mm) | 3200x1270×1770 | 3200x1270×1770 | 3500x1300×1850 | 3800x1350×1950 | 4200x1500×2100 | 4200x1500×2100 | 4800x1750×2400 |
| Net weight of silent type (kg) | 2220 | 2388 | 2600 | 3100 | 4100 | 4500 | 5200 |
